2025 New Design R32 Inverter Pool Heat Pump High Efficiency
Description
2025 new design R32 inverter pool heat pump, full DC inverter technology, max COP 6.0, energy saving over 50%. Eco-friendly R32 refrigerant, cooling and heating modes, smart WiFi control, ambient temperature range -15°C to 43°C. Various models for pool volumes 15-100 m³.
Specifications
| Model | NL-FLM25Y/32, NL-FLM35Y/32, NL-FLM50Y/32, NL-FLM60Y/32, NL-FLM70Y/32, NL-FLM80Y/32 |
| Fan type | DC motor fan – Horizontal |
| Condenser | Spiral titanium tube in PVC |
| Functions | Heating & Cooling |
| Evaperator | Hydrophilic aluminium fins & copper tubes |
| Casing type | ABS Plastic |
| Refrigerant | R32 |
| Fan quantity | 1 PCS |
| Power source | 220V 1Phase |
| Compressor type | Twin-rotary DC Inverter |
| Max Current (A) | 8, 10, 15, 18, 22, 26 |
| Net weight (kg) | 40, 42, 56.5, 65, 76, 81 |
| Gross weight (kg) | 48, 50, 66.5, 75, 86, 91 |
| Power cable (mm²) | 3×2.5, 3×2.5, 3×4.0, 3×4.0, 3×4.0, 3×6.0 |
| Circuit breaker (A) | 10, 12, 18, 20, 25, 28 |
| Water connection (mm) | 50 |
| Sound pressure@1M dB(A) | 36~46, 38~49, 41~50, 42~51, 43~53, 44~55 |
| Sound pressure@2M dB(A) | 20~26, 21~30, 23~31, 24~32, 25~36, 26~37 |
| Advised pool volume (m³) | 15~40, 20~50, 35~70, 40~80, 45~90, 50~100 |
| Advised water flow (m³/H) | 2~3, 3~4, 5~7, 6~8, 7~9, 8~10 |
| Unit dimensions (W*D*H) (mm) | 846*328*589, 846*328*589, 935*378*660, 935*378*660, 1137*423*785, 1137*423*785 |
| Operating ambient temperature | -15℃~43℃ |
| Packing dimensions (W*D*H) (mm) | 930*440*720, 930*440*720, 988*460*789, 988*460*789, 1173*502*914, 1173*502*914 |
| Cooling Capacity at Air 35℃,Water 30℃in ,28℃out - COP (W/W) | 3.12, 3.06, 4.01, 3.02, 3.15, 3.13 |
| Cooling Capacity at Air 35℃,Water 30℃in ,28℃out - Capacity (kW) | 3.43, 4.38, 6.50, 8.30, 10.11, 12.36 |
| Cooling Capacity at Air 35℃,Water 30℃in ,28℃out - Power input (kW) | 1.1, 1.43, 1.62, 2.75, 3.21, 3.95 |
| Heating Capacity at Air 15℃,Humidity 70%,Water 26℃in,28℃out - COP (W/W) | 4.71, 4.6, 4.54, 4.62, 4.65, 4.74 |
| Heating Capacity at Air 27℃,Humidity 80%,Water 26℃in,28℃out - COP (W/W) | 6.1, 6.03, 6.18, 6.02, 6.11, 6.15 |
| Heating Capacity at Air 15℃,Humidity 70%,Water 26℃in,28℃out - Capacity (kW) | 6.2, 8.3, 12.7, 14.8, 17.4, 19.8 |
| Heating Capacity at Air 27℃,Humidity 80%,Water 26℃in,28℃out - Capacity (kW) | 7.7, 10.5, 17.0, 20.0, 22.5, 26.5 |
| Heating Capacity at Air 15℃,Humidity 70%,Water 26℃in,28℃out - Power input (kW) | 1.32, 1.80, 2.80, 3.21, 3.74, 4.18 |
| Heating Capacity at Air 27℃,Humidity 80%,Water 26℃in,28℃out - Power input (kW) | 1.26, 1.74, 2.75, 3.32, 3.68, 4.31 |
