EPCB Special Oil/Gas Steam Boiler for Textile Industry
Description
EPCB customized oil/gas steam boiler for textile industry, adopts three-pass fire tube structure, equipped with intelligent control system and world-renowned brand burner, high thermal efficiency, energy saving, and environmental protection. Widely used in textile, printing and dyeing, food, chemical, pharmaceutical, and other industries.
Specifications
| Boiler fuel | natural gas, LPG, diesel, gasoline, heavy oil, etc. |
| System type | Three Pass Steam Boiler for Textile Industrial |
| Flue diameter | φ250-1500×600 mm |
| Rated capacity | 0.5-20 t/h |
| Blowdown diameter | DN 40-2×50 |
| Body heating area | 13.05-275.3 m² |
| Boiler water volume | 1.19-31.5 m³ |
| Rated steam pressure | 0.7/1.0/1.25/1.6 MPa |
| Water inlet diameter | DN 25-80 |
| Safety valve diameter | DN 40-2×100 |
| Economizer heating area | 10.4-225.5 m² |
| Rated steam temperature | 170/184/194/204 ℃ |
| Boiler thermal efficiency | 91.2-93.7% |
| Fuel consumption (Diesel) | 30.03-1169.83 kg/h |
| Main steam valve diameter | DN 50-200/65 |
| Largest transportation weight | 2300-40500 kg |
| Fuel consumption (Natural gas) | 36.72-1430.55 Nm³/h |
| Largest transportation size (Width) | 1450-3950 mm |
| Largest transportation size (Height) | 1740-4350 mm |
| Largest transportation size (Length) | 2550-9200 mm |
