OK-702C Type Four Lanes Log Saw Cutting Machine
Description
The OK-702C type four-lane circular saw log cutting machine is driven by servo motor, PLC programming control, touch screen parameter setting, suitable for paper cutting. Stable speed 200 cuts/min, design speed 250 cuts/min, adjustable cutting length, tolerance ±1mm. Equipped with pneumatic knife sharpening and spray lubrication system, power 38KW, can process 4 lanes simultaneously.
Specifications
| Model | OK-702C |
| Power | 38KW |
| Cutting lane | 4 lanes |
| Stable speed | 200 cuts/min |
| Function type | Movement of round blade in revolved swing and continuous and onward movement of paper roll with control |
| Blade-greasing | Greasing by spraying oil reek, which the greasing time can be programming controlled by panel |
| Blade-grinding | Pneumatic grinding wheel, which the grinding time can be programming controlled by panel |
| Cutting length | Variable, servo control, Tolerance±1mm |
| Designing speed | 0-250 cuts/min |
| Parameter setting | Touch screen |
| Programming control | PLC |
| Driving control for material conveying | Drived by servo motor |
| Outer dia.of round blade for paper slitting | 810mm |
